Real-time Quantitative PCR Detector: 30-Min PCR Runs for Small Labs & On-Site Testing

1. Temperature Control: Boasting a maximum heating rate of 8°C/s and maximum cooling rate of 6.1°C/s, the system completes a standard PCR amplification protocol in just 30 minutes for rapid detection. Temperature accuracy is maintained within ±0.1°C, ensuring excellent repeatability and accuracy.

2. Fluorescence Scanning: A full 48-well, 4-color fluorescence scan is completed in just 2 seconds. For users utilizing the high-resolution melting curve (HRM) function, this drastically cuts total testing time and significantly enhances workflow efficiency.

3. Versatile Multifunctionality: Beyond conventional analytical functions including relative quantification, absolute quantification, HRM, and SNP analysis, the system supports various isothermal amplification technologies for fluorescence-based assays, truly achieving multi-purpose operation with a single device.

4. Standalone Operation Capability: Equipped with a built-in 7-inch full-color touch screen, independent control system, and USB data export function, the instrument allows full experimental execution via standalone operation without requiring a connected computer.

5. Advanced Data Management: Complementing the instrument’s operating software, a dedicated independent data management software suite is provided to centralize the management, statistics, and analysis of users’ large-volume experimental data, minimizing errors associated with manual complex raw data analysis.

6. User-Friendly Interface: Featuring a fully Chinese system interface and wizard-guided parameter setup, the instrument can be mastered for standard use after basic training, enabling users to quickly gain independent experimental operation capabilities.

7. Remote Network Control: With a standard network interface, users can configure network parameters to enable remote operation, experiment monitoring, and data transmission within a local area network (LAN).

8. Customizable Reporting: The integrated universal report function allows users to adjust and customize experimental report formats according to specific requirements, establishing a unique, personalized experimental report style tailored to their needs.

9. Compact & Portable: Boasting a small footprint and lightweight design, the instrument can be easily transported to required locations or integrated into mobile laboratories for on-site testing applications.

10. Calibration-Free Mobility: Utilizing a fixed fluorescence detection unit, the instrument requires no calibration after movement, enabling immediate startup and operation upon relocation.
