Portable Mini Raman Spectrometer with High Resolution & Ideal for Lab Research
Featuring an optimized, brand-new design, the LATR2500 Raman Spectrometer offers ultra-compact size, lightweight construction, high resolution, superior sensitivity, and exceptional reliability for precise laboratory scientific research.
- modelLATR2500 Series
- brandLABEKS
- min. order1 pcs
- packageplywood case package
description
The LATR2500 employs the latest full free-space optical path technology, which enhances Raman signal collection efficiency by nearly 4 times, thus quadrupling its sensitivity. Perfectly suited for laboratory scientific research, this spectrometer boasts a compact footprint, high reliability, intuitive operation, and delivers accurate, consistent test results. Its outstanding low stray light design ensures hassle-free usage. The bundled multifunctional software has undergone rigorous testing by hundreds of scientists worldwide, with feedback incorporated into nearly 100 iterative updates, resulting in a fully functional, stable tool ideal for advancing Raman research endeavors.
features
The multifunctional software bundled with the LATR2500 Raman spectrometer has been rigorously validated by hundreds of global scientists, with nearly 100 iterative updates to ensure comprehensive, stable performance for Raman research projects. Its exceptional low stray light design enables effortless operation. With a compact form factor, high reliability, and simple testing workflows, the instrument produces consistently accurate and dependable outcomes. This Raman spectrometer is ideally suited for laboratory scientific research applications.
specifications
Model | LATR2500Series | ||
|---|---|---|---|
Integrationtime | 4ms -120s | ||
Voltage | DC 5V±5% | ||
Worktemperature | -10~45℃ | ||
Workhumidity | <95% | ||
Spectralreliability | σ/μ<0.5% (COT 8 hours) | ||
Temperaturereliability | Spectralshift ≤ 1 cm (10-40℃) | ||
Spectralintensity | <±5%（in 5 ~40℃） | ||
Spectralrange | 250-2700cm-1 | / | 200-4000cm-1 |
Resolution | 4~6 cm-1 | / | 7~10 cm-1 |
SNR | >1300:1(918 cm of Acetonitrile，4sIntergation, 130mW) | ||
Spectralrange | 200-1100nm | ||
Effectivepixels | 2048pixels | ||
Dynamicrange | 50000:1 | ||
Centerwavelength | 785±0.5nm | ||
Halfwidth | 0.08nm | ||
Maximumoutput power | ≥300 mW，theactual output power software can be set | ||
Minimumpower output adjustment | 1mW | ||
Powerstability | σ/μ<±0.2% | ||
RayleighScatter Resistance | 6 mm | ||
OperatingDistance(OD) | OD>8 | ||
NA | 0.3 | ||
Aperture | 7mm | ||
Interface | USB 2.0 | ||
Dimension(L*W*H) | Withoutprobe: 119.2×89×35 mm | ||
Withprobe: 139×89×35 mm | |||
Weight | 390 g | ||
