Petroleum Product Distillation Tester with Continuous Heating Adjustment for ASTM D86 & GB/T6536 Tests

Featuring a front-mounted single-channel layout, specialized lifting mechanism, continuously adjustable heating power, and a condenser tube with φ12mm inner diameter, this petroleum product distillation tester ensures controlled, compliant distillation analysis for petroleum-based samples.

  • model
    LYD-6536
  • brandLABEKS
  • min. order1 pcs
  • packageplywood case package

description

Engineered and manufactured in strict adherence to GB/T6536 “Test Method for Distillation Characteristics of Petroleum Products” and ASTM D86 “Standard Test Method for Distillation of Petroleum Products at Atmospheric Pressure”, this instrument is designated for determining the distillation characteristics of gasoline, aviation gasoline, jet fuels, special boiling point solvents, naphtha, diesel oil, distillate fuels, and comparable petroleum-based products.

features

1. The condenser tube water bath integrates precise temperature control, with an adjustable range of (room temperature + 10) ℃～ 60 ℃; uniform bath temperature fully satisfies all mandatory test requirements.

2. A specialized heating furnace is incorporated to guarantee operational safety, with heating power that can be continuously adjusted for precise thermal regulation.

3. A dedicated lifting device enables free elevation adjustment of the distillation flask, providing flexible and straightforward operation during testing procedures.

specifications

Model

LYD-6536

Powersupply

AC(220±10%)V,50Hz

Totalpower consumption

≤2000W;

Receivingcylinder

100ml，scaledivision 1ml

Distillationflask

125mL.It can meet requirements GB/T 6536 and ASTM D86

Waterbath temperature controlling

(1) Range:（ambient temp.+10）℃～60℃

(2) Accuracy:±0.5℃

Ambienttemperature

15℃～35℃

Relativehumidity

≤85%

Dimension

460mm×400mm×550mm

Netweight

18.5kg.

why choose us

  • Premium Quality with CE & ISO

    We conduct 100% performance testing on every unit, ensuring its stable operation and superior performance in your application.

  • 24/7 Expert Technical Support

    Our senior engineers are on standby 24/7, ready to provide expert solutions at any time to minimize your operational downtime.

  • 20+ Years R&D & Production

    Our deep technical expertise is your solid guarantee for professional and reliable OEM/ODM services.

  • Trusted in 80+ Countries

    Industry leaders and research institutions in over 80 countries and regions rely on our equipment for stable operation.

  • True Manufacturer, Factory-Direct Price

    Bypass the middlemen to get our factory pricing and speak directly with our core engineers.

  • Rapid & Reliable Delivery

    Our extensive in-stock inventory provides a solid guarantee for rapid and reliable global delivery.
