Orbital Shaker with 50mm Amplitude for Biopharmaceutical & Pilot Trial Applications
Ideal for centralized constant-temperature cluster oscillation in dedicated thermostatic rooms, this orbital shaker delivers high-efficiency performance for mass production, biopharmaceutical research, pilot trials, and large-scale strain screening, paired with robust safety systems and programmable controls.
- modelLH-3432
- brandLABEKS
- min. order1 pcs
- packageplywood case package
description
The LH series orbital shaker is engineered for centralized constant-temperature cluster oscillation within dedicated thermostatic environments. It provides exceptional oscillation efficiency for mass-scale production operations, biopharmaceutical research initiatives, pilot trials, and high-throughput strain screening, while offering strong cost-effectiveness and practicality. LH-311TD/322TD models feature an extra-large 100mm amplitude. The LH-300D/311D/322D series are single-layer units with a 50mm amplitude. LH-3112/3222/3332/3432 (including the LH-3432 model) are double-layer high-capacity units boasting a 50mm amplitude. For reciprocating oscillation needs, the LH-331/332/3312 series operate at a speed range of 50-300rpm/min.
features
1. Integrated watchdog timers, independent overspeed audio-visual alarms, and isolated leakage/overcurrent protection ensure operations do not disrupt adjacent equipment.
2. Exclusive motor overheating and temperature out-of-control automatic shutdown protection mechanism.
3. A specialized slow-start function prevents abrupt activation and reagent splashing, safeguarding sample integrity.
Security
1. Leakage current and overcurrent protection systems are in place to safeguard operator safety.
2. Over-temperature and overspeed audio-visual alarm systems with emergency controls protect sample safety.
3. 8-segment user-programmable functionality allows for independent speed and time settings for each segment, enabling customized oscillating protocols.
4. A PID microprocessor-based control and monitoring system enables intuitive button operation and straightforward time and speed programming.
5. High-precision frequency control system maintains rotational accuracy within ±1rpm for consistent performance.
6. Features include automatic start/stop, timed operation, clock display, parameter recall, and memory functions for seamless workflow.
7. The system automatically memorizes the last set speed and ramps up gradually to this speed upon power restoration.
8. Equipped with a high-torque, maintenance-free motor that supports reliable continuous operation.
9. An original domestic single-axis drive mechanism ensures quiet, long-lasting performance.
10. State-of-the-art domestic machining and finishing technologies ensure stable and reliable mechanical performance.
11. Critical drive components are crafted from premium chrome alloy, high-quality cast iron, and original imported bearings for enhanced durability.
12. The cabinet construction utilizes high-strength cold-rolled steel, channel steel, angle steel, and cast iron for robust structural integrity.
13. The electrostatic powder-coated enclosure offers an attractive, rust-resistant finish with a modern aesthetic.
specifications
Model | LH-3432 |
|---|---|
Controlmethod | PIDmicrocomputer environment scanning micro-processing chip control |
Displaymethod | LCD liquidcrystal display |
Programmingcontrol | Eight-segmentuser-programming |
Safetyprotection | Automaticoperation, automatic stop, timed operation, clock display, call recovery,parameter memory |
Accessoryfunction | Watchdogtimer, independent overspeed sound/light alarm, independent leakage, leakageovercurrent protection device |
Cyclic mode | Naturalconvection |
Oscillationmode | Rotaryoscillation |
Drive mode | Multidimensionaldrive |
Environmentalrequirements | User-specificthermostat or environment |
Rotationfrequency | 30-300rpm |
Timing range | 0-999.59hours / sustainable |
Rotationaccuracy | ±1rpm |
Pendulumamplitude | φ50mm |
Rocker size | 1080*680(mm) |
Number ofrocking plates | SIX |
net weight | 850kg |
Dimensions | 1590*1120*1310(mm) |
Outer box material | High qualityand high strength cast iron, channel steel, angle steel, cold rolled steel |
Power supply | AC 200-240V50-60HZ |
Power | 1100W(Inverter motor) |
