LPCR-TS Intelligent Economy Thermal Cycler: Boasting 4.5℃/s Heating Rate and GLP-Compliant Experimental Reports

Packed with advanced integrated technologies including a WINCE operating system, full-color touchscreen, interchangeable modules, and PC connectivity, this thermal cycler delivers reliable, high-performance operation to meet the demands of complex qualitative PCR experiments.

  • model
    LPCR-TS Series
  • brandLABEKS
  • min. order1 pcs
  • packageplywood case package

description

Featuring a maximum temperature ramp rate of over 4.5℃ per second and a service life exceeding 200,000 cycles, this thermal cycler integrates a comprehensive suite of advanced technologies: WINCE operating system, full-color touchscreen, multiple interchangeable modules, PC connectivity, printing capability, large-capacity data storage, and expandable functions. These features optimize the performance of qualitative PCR applications to the highest standard, delivering robust functionality that satisfies the requirements of high-precision experimental workflows.

features

1. Ultra-fast temperature ramp rates of up to 4.5℃/s (heating) reduce experimental turnaround times significantly;

2. Six specialized long-life Peltier temperature control modules form three independent loop systems, enabling precise, zone-specific temperature regulation;

3. Anodized, engineering-grade reinforced aluminum block maintains exceptional thermal conductivity while providing superior corrosion resistance;

4. Intuitive WINCE-based full-color touchscreen interface features an 8-inch high-definition TFT display (800 x 600 pixels, 16 true colors) with graphical menu navigation for effortless operation;

5. One-touch rapid incubation mode supports denaturation, enzyme digestion/ligation, ELISA, and related experimental workflows;

6. 11 pre-loaded standard program templates enable rapid customization of experimental protocols;

7. Protocol organization is streamlined via folder-based management, allowing users to create custom directories for easy file sorting;

8. Real-time display of protocol progress and remaining run time, with support for on-the-fly programming adjustments during operation;

9. High-capacity data storage allows for the retention of up to 10,000 experimental protocol files;

10. Customizable hot lid temperature and operating modes are available to accommodate diverse experimental needs;

11. Stepless adjustable hot lid accommodates test tubes of varying heights and locks into place at any angle when opened;

12. Automatic power failure protection resumes interrupted cycles automatically once power is restored, safeguarding the integrity of amplification processes;

13. GLP-compliant experimental reports document every step of protocol execution, providing precise data to support result analysis;

14. Three-tiered user login management with password protection ensures secure access to sensitive experimental data;

15. USB 2.0 interface enables data export/import via USB flash drive, and supports control via external USB mouse;

16. Software updates can be performed conveniently via USB flash drive or LAN connection;

17. Centralized control of multiple thermal cyclers is achievable via network connectivity;

18. Optional compact wireless Bluetooth printer enables easy, accurate documentation of experimental protocol details;

19. Email notification functionality sends automatic alerts upon completion of an experimental run;

specifications

Model

LPCR-9612TS

LPCR-9632TS

LPCR-6022TS

LPCR-3842TS

Capacity

96×0.2ml

96×0.2ml+77×0.5ml

60×0.5ml

384well

Temperature Range

0~100℃

Heating Rate

4.5℃/s

Cooling Rate

4℃/s

Uniformity

≤±0.2℃

Accuracy

≤±0.1℃

Display Resolution

0.1℃

Temperature Control

Block\Tube

Ramping Rate Adjustable

0.1~4.5℃

Gradient Uniformity

≤±0.2℃

Gradient Accuracy

≤±0.2℃

Gradient Temp. Range

30~100℃

Gradient Spread

1~30℃

Hot Lid Temperature

30~110℃

Hot Lid Height Adjustable

Stepless Adjustable

Number of Programs

10000 +(USB FLASH)

Max.No.of Step

30

Max.No.of Cycle

100

Time Increment/Decrement

1 Second ~600Second

Temp. Increment/Decrement

0.1~10.0℃

Pause Function

Yes

Auto Data Protection

Yes

Hold at 4℃

Forever

Language

Chinese/English

Print

Yes

LAN to computer

Yes

LCD

8 inch,800×600 pels, 260000 colors

Communication

USB2.0 , LAN

Dimensions

390mm×270mm×255mm (L×W×H)

Weight

8.5kg

Power Supply

85~264VAC , 47~63Hz , 600 W
