Liquid Petroleum Products Hydrocarbon Tester for Measuring Aromatic, Olefin & Saturated Hydrocarbon Percentages
Designed to meet strict national and international standards, this hydrocarbon tester accurately determines the volume percentages of aromatic hydrocarbons, olefins and saturated hydrocarbons in liquid petroleum fractions, serving as a critical quality assessment tool for engine fuels, aviation fuels and other fuel oils.
- modelLYD-11132
- brandLABEKS
- min. order1 pcs
- packageplywood case package
description
Engineered in strict accordance with China’s national standard GB/T 11132 and ASTM D 1319—both standard test methods for hydrocarbon types in liquid petroleum products via fluorescent indicator adsorption—this tester enables key hydrocarbon components of liquid petroleum products to be clearly visualized on silica gel adsorption columns with fluorescent indicators. The calculated volume percentages from these visualizations act as essential quality metrics for engine fuels, aviation fuels and other fuel oils.
As a specialized analytical instrument, it precisely measures the volume percentages of aromatic hydrocarbons, olefins and saturated hydrocarbons present in petroleum fractions.
features
1. Two imported precision glass tube adsorption columns ensure straightforward, hassle-free operation.
2. Integrated adsorption column cleaning unit resolves the common challenge of cleaning adsorption columns efficiently.
3. Vertical, one-piece design allows for immediate use without any assembly requirements.
4. The tester comprises an air circuit system, vibration unit, scale indicator, illumination module and UV light detection component.
specifications
Model | LYD-11132 |
|---|---|
Power supply | AC(220±10%)V,50Hz |
Maximum power consumption | 600W |
Pressure regulating range ofreducing valve | (0～400)kPa |
Electric agitator | independently controlled foreach way |
Ultraviolet light source pipe | 1220mm in length,wavelength is365mm±5nm |
Illuminating lamp | 1220mm in length，power is 40W |
Air supply | Nitrogen cylinder (or aircompressor,compressed air bottle) |
Ambient temperature | (15～35)℃ |
Relative humidity | ≤85% |
Dimension | 350mm×400mm×1770mm |
Net weight | 24kg |
