Dry Scroll Pump with 8000 Hours Continuous Runtime for Semiconductor & Lab Use
Offering exceptional pumping capacity, superior ultimate vacuum performance, and advanced design elements, the Dry Scroll Pump (2nd-gen scroll structure) delivers increased pumping speed, lower power consumption, reduced noise, and extended seal replacement intervals for critical vacuum operations.
- modelSPH Series
- brandLABEKS
- min. order1 pcs
- packageplywood case package
description
Featuring a 2nd-generation scroll pump structure, the SPH dry scroll pump boasts exceptional pumping capacity, superior ultimate vacuum performance, and advanced design attributes. Optimized from the first-generation scroll pump, this unit delivers increased pumping speed, higher ultimate vacuum levels, reduced power consumption, and lower operational noise. With its gas ballast function, it can effectively evacuate smaller volumes of condensable vapors such as water, solvents, dilute acids, and alkalis. Furthermore, its optimized face seal technology dramatically extends the interval between face seal replacements, rendering it highly suitable for applications involving water vapor and certain corrosive substances.
features
1. 8000 hours of guaranteed continuous operation.
2. Optimized scroll disc design.
3. Optimized face seal technology.
4. High-flow gas ballast feature.
5. Permanent magnet variable-frequency motor.
6. Variable frequency temperature-regulated fan.
7. Dual Band & Pressure capability.
8. Suitable for laser processing, semiconductor manufacturing, molecular pump foreline use, accelerators, analytical instruments, vacuum glove boxes, leak detection systems, vacuum recovery units, pharmaceutical R&D, electron beam welding, and packaging applications.
specifications
Model | SPH10 | SPH15 | SPH20 |
|---|---|---|---|
Pumpingspeed (m³/h) | 10m³/h (6.7cfm) | 15m³/h (8.9cfm) | 20m³/h (13cfm |
Ultimatepressure | 2pa/0.02 mbar | 1pa/0.01 mbar | |
Rotaryspeed(rpm) | 1800rpm | ||
Connector | KF25 | ||
Powersupply (w) | 550W | 750W | |
Ratedpower (v) | 100-240V/50-60HZ | ||
Dimensions(mm) | 442*278*308mm | ||
Weight(kg) | 25.2kg（56 lb） | 25.6kg（56 lb） | 25.8kg（57 lb） |
Vapourpumping Ability(g/h) | 140 | 200 | |
Noiselevel (dbA) | 55dbA | ||
Coolingmethod | （Air-cooling） | ||
Workingtemperature | 5-45℃ | ||
