Bottom Magnetic Mixing Stainless Steel Fermenters: Leak-Free Solution for Sterile Plant & Animal Cell Culture
Ideal for long-cycle cultures with strict biosafety standards and low-viscosity media, stainless steel fermenters with bottom magnetic mixing support the cultivation of plant cells, animal cells, and slow-growing microorganisms.
- modelLBR-XSC Series
- brandLABEKS
- min. order1 pcs
- packageplywood case package
description
Equipped with a robust bottom magnetic stirring system, our stainless steel fermenters feature a fully sealed, dead-leg-free 316L stainless steel tank. By converting dynamic seals to static seals, these systems achieve zero leakage and contamination-free operation, thoroughly eliminating the risk of bacterial contamination in bioprocess culture tanks. They are ideal for long-cycle cultures and non-dominant bacterial cultivation.
features
Integrates a high-strength bottom magnetic stirring system that uses static seals instead of dynamic seals, ensuring full enclosure, zero leakage, and contamination-free operation to eliminate bacterial contamination risks in bioprocess culture tanks.
Constructed from 316L stainless steel with all product-wetted components made of the same material; the tank lid offers an unobstructed view, and the smooth, Ra≤0.4 polished surfaces enable easy operation and cleaning.
Supports in-situ sterilization capability for hassle-free, thorough sanitization.
Offers precise fermentation pH control via an intelligent PID system and dedicated pH electrode.
Provides accurate dissolved oxygen (DO) control for fermentation processes with an intelligent PID system and specialized DO electrode.
Equipped with a two-stage straight-blade stirring paddle and a single-stage mechanical compression defoaming paddle.
Combines electric heating and water cooling systems for excellent heat exchange efficiency during fermentation.
Comes with a complete medium replenishment system to support continuous culture needs.
Powered by a durable AC motor that delivers reliable performance even in harsh operating environments.
Features a rotameter for visual gas flow monitoring, allowing operators to adjust airflow as per process specifications.
specifications
Model | LBR-XSC series |
|---|---|
Volume | 5~5000L optional |
Diameter to height ratio | 1:2~2.5 |
Feeding volume | 70% |
Material | Stainless steel 304/316 |
Function | PH/DO/Foam/Temp control |
Tank pressure | manual adjustment, pressure gaugedisplay; range: 0~0.20Map; |
Sterilization method | Automatic or manual sterilization |
Stirring Speed | 50~700rpm stepless speed;accuracy: ±1rpm |
Temperature detection | range: cooling water temperature+5~55℃; accuracy: ±0.1℃; resolution: 0.1℃; |
pH detection | range: 2~12ph; control accuracy:±0.02ph, resolution: 0.01ph; |
DO detection | range: 0~100%, control accuracy:±3%; resolution: 0.1%; |
Foam control | electrode detection, peristalticpump replenishing |
Ventilation | manual adjustment, flow meterdisplay; |
