Artificial Climate Incubator with Multi-Alarm Protection for Life Sciences Research

Equipped with over-temperature and humidity alarm mechanisms, the artificial climate incubator delivers precise controlled environments tailored for life sciences, pharmaceutical, and agroforestry research applications.

  • model
    LGX-P Series
  • brandLABEKS
  • min. order1 pcs
  • packageplywood case package

description

Ideal for agroforestry research, fundamental studies, quality control of Arabidopsis, plant tissue culture, life sciences, pharmaceutical sectors, and other related fields.

features

1. Illumination is provided by an LED light source, which emits growth-promoting light for plants while consuming approximately 80% less energy than conventional light sources.

2. The LED light source offers stable performance, rapid response, and an extended lifespan of up to 30,000 hours or longer.

3. High-luminous-flux LED light source with three or four-sided illumination ensures consistent light distribution throughout the incubator.

4. Equipped with an imported Honeywell humidity sensor for highly accurate humidity measurements.

5. A concealed thermal humidification system is integrated, outperforming direct inner-liner heating systems. It delivers a wider humidity control range, more uniform distribution than ultrasonic humidifiers, and resists condensation buildup.

6. Integrated automatic water supply system with an internal storage tank; the system automatically replenishes water when levels are low and shuts off the pump when the tank is full, ensuring quiet, uninterrupted operation.

7. Independent humidification module ensures consistent, uniform humidity distribution within the chamber.

8. Comprehensive alarm monitoring system triggers alerts for over-temperature, over-humidity, water shortage, pump malfunction, and dry-burning incidents.

9. An independent electronic temperature limiter system (separate from the main control unit) delivers precise temperature threshold control.

10. Built-in loop self-diagnosis functionality, with alarms for sensor malfunctions and upper/lower temperature limit breaches.

11. 30-segment program control via LCD interface supports repeated stepping and step-by-step operation.

12. User-friendly operation includes fixed-value mode, timed operation, and automatic shut-off functions.

13. Dedicated function keys enable quick, straightforward temperature adjustment.

14. An auxiliary menu provides access to over-temperature alarm settings, deviation correction, and menu locking capabilities.

15. Turbine-driven centrifugal forced air circulation ensures uniform temperature distribution throughout the incubator chamber.

16. Power failure protection preserves all set parameters, with one-touch recovery functionality upon power restoration.

17. Power outage protection with parameter memory and one-touch call recovery features.

18. Compressor overload protection is included to prevent equipment damage and extend service life.

19. The air intake grille can be opened directly for convenient condenser cleaning and maintenance.

20. Intelligent defrosting functionality prevents frost buildup and maintains optimal chamber conditions.

specifications

Model

LGX250P/

LGX250PF

LGX300P/

LGX300PF

LGX400P/

LGX400PF

Performance

Temperaturecontrol range

No light : 0-65℃;

With light: 10-65℃

Temperatureresolution

±0.1℃

Constant temperature fluctuation

±1℃

Temperatureuniformity

1.5℃(37℃)

Humiditycontrol range

35%-90%

Humidityfluctuation

±3%

Humiditydistribution accuracy

±3%

Lightintensity

0-30000LX

0-33000LX

0-33000LX

0-35000LX

Lightingmode

LEDlighting, 10 levels adjustable

Work environment

+5-35℃

Constitute

Heatingpower

1000W

Compressorpower

174W

Humidificationpower

1000w

Lightingpower

246W(P)

336W(PF)

270W(P)

360W(PF)

maximumpower

1420W

1510W

2587W

2677W

2845W

2935W

compressor

Air cooledhermetic compressor

Cryogen

R134A

Humiditycontrol method

Automaticcontrol, hidden heating

Humiditycontrol method

Automaticcontrol, hidden thermal humidification

Defrostingstructure

Automatic

Controller

Temperaturecontrol mode

30 stageprogram control

Temperaturesetting mode

P: Touch sixbuttons to display LCD

Controller

Large screencolor printing LCD controller

Operationfunction

Constantvalue operation, Program running

Additionalfunctions

Electronicdigital temperature limiter; deviation correction; intelligent defrosting

Controller

Sensor

PT100

Specifications

Internaldimensions (mm)

500*530*950

550*580*950

590*620*1100

Dimensions(mm)

690*705*1650

740*755*1650

780*795*1800

Outerpackage size

890*905*1870

940*955*1870

980*990*2020

Internalvolume

250L

300L

400L

Diaphragmbearing

15kg

Number ofdiaphragm layers

6

6

7

Diaphragmspacing

120mm

Ratedcurrent

AC220V50HZ(16A3 phase)

Net / grossweight

78/120

80/121

83/125

Accessories

Partition

2

Partitionframe

4

Configurationcan be increased

Diaphragm,RS485 interface, printer, recorder, external communication, remote control,wireless SMS alarm, U disk data storage, red and blue light plant growth lamp
