200kg Vacuum Freeze Dryer for Food & Pharmaceutical Processing
The LG-20 vacuum freeze dryer from LABEKS supports freeze-drying over 20 food categories including meats, vegetables, fruits, aquatic products, beans, beverages, soups, and health products, enabling long-term storage while retaining natural nutrients and ensuring convenient end-use.
- modelLG-20
- brandLABEKS
- min. order1 pcs
- packageplywood case package
description
The LG-20 large-scale vacuum freeze dryer is extensively utilized across pharmaceuticals, biomedical research, chemical processing, and food production sectors. Following the freeze-drying process, products can be easily stored for extended periods and will revert to their original state while preserving all inherent chemical and biological properties upon rehydration.
features
Integrated split structure for simultaneous pre-freezing and drying, boosting freeze-drying efficiency and reducing overall processing time.
Advanced drying curve optimization algorithm enables precise regulation of product heating rates and vacuum levels throughout the drying phase.
Industrial-grade embedded touchscreen paired with the dedicated SH-HPSC-III modular controller ensures a highly stable, reliable system with superior control precision.
The purpose-built FD-MANAGER control system supports storage of multiple process recipes, with real-time process adjustment capabilities to enhance optimization throughout drying cycles.
Constructed with aerospace-grade aluminum alloy partitions featuring double-sided radiant heating, achieving over 90% emissivity and excellent temperature uniformity across surfaces.
High-performance mixed refrigerant with a low freezing point and high boiling point, ensuring exceptional heat exchange efficiency and an extended operational lifespan.
Specialized gas diversion design and control technology deliver robust water capture capabilities and enhanced drying efficiency.
Trays are precision-stamped from aviation-grade rust-proof aluminum alloy; after specialized surface treatment, they exhibit high heat absorption. Each drying chamber comes fitted with 2 sets of these trays.
Versatile manual + automatic control modes: manual mode for process development, automatic mode for large-scale mass production.
Accurate sensor calibration functionality guarantees the precision of process parameters during prolonged operational use.
Configurable user access levels and password protection enable structured, decentralized operational management.
Optional high-performance LYO-MEGA host computer control system stores operational data, curves, and alarm records for up to 10 years to enhance product traceability, while simplifying monitoring, operation, and fault diagnosis.
Custom non-standard configurations are available to meet specific user requirements.
specifications
Model | LG-20 |
|---|---|
Freeze drying area (m2) | 20.6 |
Loading Capacity (kg) | 200 |
Shelf numbers (Layers) | 8+1 |
Shelf dimensions (mm) | 1200*2150*15 |
Shelf spacing (mm) | 80 |
Cart numbers (set) | 2 |
Ice collecting capacity (kg/batch) | ≥300 |
Cold trap temperature (℃) | ≤-60 |
Defrosting mode | water cooled，water temperature＜30℃ |
Defrosting mode | spraying + soaking |
Ultimate vacuum (Pa) | ＜5 |
Power (kw) | 96 |
Water cooled consumption (m3/h) | 40 |
Compressed air L/min(P=0.5~0.8Mpa) | 30 |
Dimensions (L*W*H) (mm) | 6200*2300*3200 |
Overall weight (kg) | 10 |
