1064nm Handheld Raman Spectrometer Analyzer with Fluorescence Suppression for Forensic & Gemstone Identification
Designed for substance composition confirmation and identification, this Raman Spectrometer Analyzer supports applications across research institutions, university physics & chemistry labs, biomedicine, criminal investigations, and the jewelry sector for drug detection and gemstone verification.
- modelLATR6600
- brandLABEKS
- min. order1 pcs
- packageplywood case package
description
The LATR6600 is a handheld 1064nm Raman spectrometer with enhanced fluorescence suppression. Leveraging the inherent ultra-high fluorescence inhibition properties of its 1064nm excitation source, it is ideally suited for testing fluorescent samples.
Weighing under 1 kg with a compact form factor, this device offers exceptional portability. It enables rapid identification of drugs, precursor chemicals, explosives, jewelry, jade, raw materials, and more at customs checkpoints, law enforcement labs, transportation hubs, and dockyards. A key focus is the fast detection and verification of food additives, pesticide residues, and veterinary drug residues.
Equipped with a high-performance integrated Raman spectral recognition algorithm, the LATR6600 enables non-selective substance detection, straightforward identification, and supports user-customized spectral library additions. Running on the Android operating system, it features an intuitive, user-friendly interface, a 5.5-inch display, and a 13MP high-definition camera for on-demand detection scene recording. Built-in modules include WIFI, Bluetooth, and GPS for seamless, intelligent operation.
LABEKS offers comprehensive technical support and services, including spectral library development, method validation, and IQ/OQ/PQ certification assistance.
features
1. 1064nm excitation source for effective fluorescence interference reduction;
2. Non-destructive, rapid detection and identification with one-click operation;
3. Advanced algorithm enabling accurate mixture detection;
4. Customizable self-built spectral library support;
5. Generatable test reports and spectral plotting functionality;
6. 5.5-inch capacitive touch screen with sharp display and intuitive control;
7. 13MP high-definition camera;
8. Compatibility with barcode and QR code scanning functionality;
9. High-precision GPS positioning capability;
10. Multi-channel communication support including 4G, GSM, GPRS, Bluetooth, and WI-FI;
11. Integrated lithium battery with 4-6 hours of continuous operation time;
12. Ultra-lightweight (0.96 kg) for effortless portability;
13. IP67-rated industrial-grade dust and water resistance;
Application:
1. General substance identification;
2. Law enforcement anti-narcotics operations (detectable heroin, fentanyl, etc.);
3. Detection of hazardous chemicals in high-speed rail and subway entrances;
4. Identification of raw and auxiliary materials in the pharmaceutical industry;
5. Food safety testing;
6. Gem and jewelry authentication;
specifications
Model | LATR6600 | ||
|---|---|---|---|
Features | Super strongfluorescence suppression effect | ||
Operatingsystem | Android | ||
Laserwavelength | 1064±0.5nm | ||
Laser power | 0-600mWadjustable | ||
Wave numberrange | 200-2500cm-1 | ||
Resolution | 8-15cm-1 | ||
Touch screen | 5.5inch,1920×1080, multi touch | ||
Detector | TE cooledInGaAs | ||
Size | 220x110x45mm | ||
Weight | 970g | ||
Communicationinterface | WIFI、USB、Type-C、Bluetooth、GSM | ||
Export Report | Support for exporting multi-information test reports (test results,spectrum information, photo forensics), txt, pdf, etc. | ||
Battery | 4-6hour continuous operation | ||
Charging Type | USB Type-C | ||
Operating Temperature | -20 ~ 50°C | ||
Application&Library | Item | Spectral Library | Application |
LATR6600 | Self-built Spectral Library | Scientific Research | |
LATR6600-DH | lDrugs: heroin, methamphetamine, cocaine, Kpowder, fentanyl, alprazolam, etc. lEasy to produce poison: ephedrine, chloroform,ether, etc. lExplosives: TNT, RDX, PETN, TATP, ammoniumnitrate, hexolkin, Octogen, etc. lHazardous chemicals: alcohol, sulfuric acid,gasoline, nitric acid, toluene, potassium dichromate, etc. lFood safety: pesticides, illegal food additives,etc. | Public security, customs, subway, court, prison, public places | |
LATR6600-PH | Pharmaceutical raw materials testing, etc. | Pharmaceutical Factory | |
LATR6600-GM | Gemstones: Diamond, Agate, Emerald… | Jewelry appraisal | |
LATR6600-IN | Chemicals, plastics, rubber, polymers, composites, etc. | Industrial applications | |
LATR6600-FTN | REMIFENTANIL、Brifentanil、Lofentanil、Trefentanil、 Ocfentanil、Carfentanil、alfentanil、Mirfentanil、FENTANYL-D5、ALFENTANILHYDROCHLORIDE、SUFENTANIL CITRATE、FentanyI citrate etc, more than 40kinds. | ||
